STALK ADAPTER CHINA HU LEAD F. CX401 chinahulead

STALK ADAPTER CHINA HU LEAD F. CX401 chinahulead
Out Of Stock
STALK ADAPTER CHINA HU LEAD F. CX401 chinahulead
0 reviews • Write a review
from
$20.00
Ex Tax: $20.00
  • Stock: Out Of Stock
  • Brand: Acv Lead
  • Model: 95324
Out Of Stock
Buy Now Question?
Add to Wish List Compare this Product

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

STALK ADAPTER CHINA HU LEAD F. CX401 chinahulead

Radioanschlusskabel  42a / 42cx401 > Blaupunkt / China HU / ESX / Kenwood / Snooper

Radiohersteller verwenden für den Anschluss eines Lenkradfernbedienungsinterfaces unterschiedliche Varianten.Je nach Hersteller und Gerät können Einkabelsteuerungen, Zwei- und Mehrkabelsteuerungen sowie Klinkensteuerungen Verwendung finden.
Die Anschlussvariante geht aus der BDA des Radioherstellers hervor.Alle Anschlüsse müssen vor der Verbindung des Interfaces mit dem Fahrzeug getätigt werden.Gegebenenfalls muss zusätzlich die LFB-Funktion laut BDA des Radioherstellers in einem Radiomenü angelernt werden.Vor der Endmontage auf Funktion prüfen.

Hinweis:

  • Anschluss: 4 Pin Molex > Key1 / Key2 / GND Anschluss
  • LFB-Radioanschlusskabel für 42cx401 LFB Interface 42a-xxxx-xxx
  • DIP-Schalter Einstellungen (ON/OFF)
  • Atoto Nachrüstgeräte nicht unterstützt

Für folgende Anwendung:

  • China HU Key1 / Key2 / (GND) Anschluss
  • Blaupunkt 2010> Key1 / Key2 / (GND) Anschluss
  • ESX Key1 / Key2 Anschluss
  • Kenwood 2020> Key1 / Key2 / GND Anschluss
  • Snooper Key1 / Key2 Anschluss

DIP Schaltereinstellung 42cx401:

  • Blaupunkt 2010> > OFF/ON/OFF (OFF/ON/ON)
  • China HU > OFF/ON/OFF
  • ESX > OFF/ON/OFF
  • Kenwood 2020>  > OFF/ON/OFF (OFF/ON/ON)
  • Snooper > OFF/ON/OFF
Default
Produkt Gruppe China Head Unit
